¡ù 4-ports high level output up to 116 dB¦ÌV.
¡ù Within duplex filters, high-pass or low-pass split frequency optional.
¡ù Fine aluminum die cast housing, Dacromet, heat dissipation well, water-proof, radiation proof, anti-interference.
¡ù Optical receiver module, return optical transmitter module and the network management transponder can be hot-swappable, user upgrade conveniently.
¡ù 860MHz and 750MHz frequencies optional.
¡ù Fiber optical adapter mounted on the sending / receiving modules directly, ease of installation.
¡ù Each path can be fed and have a separate 60V feed port.
¡ù Each path has the -20dB monitor port for positive output level and return input level.
¡ù The positive output level, return input level and positive slope of each path can be adjusted.
¡ù With two grades of lighting protection. |
